Positional control of chemical reaction a step toward advanced nanotechnology

A major feature of the advanced nanotechnology to be implemented in nanofactories will be positional mechanosynthesis—precise mechanical control of how reactive molecules and molecular fragments interact. In an important step toward that goal, scientists at UCLA and the University of Washington have shown that two molecules can be positioned on a surface to produce a reaction that would not occur if they were free to move in solution. By way of Science Daily, an article by Mike Rodewald from the UCLA Newsroom “New method for studying molecule reactions a breakthrough in organic chemistry“:

UCLA nanotech research mimics enzymes in directing chemical reactions

Good chemists are passive-aggressive — they manipulate molecules without actually touching them.

In a feat of manipulating substances at the nanoscale, UCLA researchers and colleagues demonstrated a method for isolating two molecules together on a substrate and controlling how those two molecules react when excited with ultraviolet light, making detailed observations both before and after the reaction. …

“This is one step in measuring and understanding the interactions between light and molecules, which we hope will eventually lead to more efficient conversion of sunlight to electrical and other usable forms of energy,” said lead study author Paul S. Weiss, a distinguished professor of chemistry and biochemistry who holds UCLA’s Fred Kavli Chair in Nanosystems Sciences. “Here, we used the energy from the light to induce a chemical reaction in a way that would not happen for molecules free to move in solution; they were held in place by their attachment to a surface and by the unreactive matrix of molecules around them.”

Weiss is also director of UCLA’s California NanoSystems Institute (CNSI) and a professor of materials science and engineering at the UCLA Henry Samueli School of Engineering and Applied Science.

Controlling exactly how molecules combine in order to study the resulting reactions is called regioselectivity. It is important because there are a variety of ways that molecules can combine, with varying chemical products. One way to direct a reaction is to isolate molecules and to hold them together to get regioselective reactions; this is the strategy used by enzymes in many biochemical reactions.

“The specialized scanning tunneling microscope used for these studies can also measure the absorption of light and charge separation in molecules designed for solar cells,” Weiss said. “This gives us a new way to optimize these molecules, in collaboration with synthetic chemists. This is what first brought us together with our collaborators at the University of Washington, led by Prof. Alex Jen.”

Alex K-Y. Jen holds the Boeing-Johnson Chair at the University of Washington, where he is a professor of materials science and engineering and of chemistry. The theoretical aspects of the study were led by Kendall Houk, a UCLA professor of chemistry and biochemistry who holds the Saul Winstein Chair in Organic Chemistry. Houk is a CNSI researcher.

The study’s first author, Moonhee Kim, a graduate student in Weiss’ lab, managed to isolate and control the reactions of pairs of molecules by creating nanostructures tailored to allow only two molecules fit in place. The molecules used in the study are photosensitive and are used in organic solar cells; similar techniques could be used to study a wide variety of molecules. Manipulating the way molecules in organic solar cells come together may also ultimately lead to greater efficiency.

To isolate the two molecules and align them in the desired — but unnatural — way, Kim utilized a concept similar to that of toddler’s toys that feature cutouts in which only certain shapes will fit.

She created a defect, or cutout, in a self-assembled monolayer, or SAM, a single layer of molecules on a flat surface — in this case, gold. The defect in the SAM was sized so that only two organic reactant molecules would fit and would only attach with the desired alignment. As a guide to attach the molecules to the SAM in the correct orientation, sulfur was attached to the bottoms of the molecules, as sulfur binds readily to gold.

“The standard procedure for this type of chemistry is to combine a bunch of molecules in solution and let them react together, but through random combinations, only 3 percent of molecules might react in this way,” UCLA’s Houk said. “Our method is much more targeted. Instead of doing one measurement on thousands of molecules, we are doing a range of measurements on just two molecules.”

After the molecules were isolated and trapped on the substrate, they still needed to be excited with light to react. In this case, the energy was supplied by ultraviolet light, which triggered the reaction. The researchers were able to verify the proper alignment and the reaction of the molecules using the special microscope developed by Kim and Weiss.

The research was published in Science (abstract). The figures and supporting material can be downloaded without a subscription.

The regioselectivity demonstrated in this research will probably not be precise enough or robust enough for diamond mechanosynthesis, but this is an elegant demonstration of the principle of positional control of chemical synthesis that will advance the underlying scientific understanding of how molecular interactions can be controlled and may also have near-term implications for improved solar cells.
