Nanotechnology provides patch to regenerate heart tissue

Advanced systems for drug delivery (for example) are not the only means by which nanotechnology is contributing to the advance of medicine. Various types of nanomaterials are showing promise as scaffolding for tissue engineering and repair and regenerative medicine. Physorg.com points to this Brown University news release “Researchers create nanopatch for the heart“:

Engineers at Brown University and in India have a promising new approach to treating heart-attack victims. The researchers created a nanopatch with carbon nanofibers and a polymer. In laboratory tests, natural heart-tissue cell density on the nanoscaffold was six times greater than the control sample, while neuron density had doubled. Results are published in Acta Biomaterialia [abstract].

When you suffer a heart attack, a part of your heart dies. Nerve cells in the heart’s wall and a special class of cells that spontaneously expand and contract — keeping the heart beating in perfect synchronicity — are lost forever. Surgeons can’t repair the affected area. It’s as if when confronted with a road riddled with potholes, you abandon what’s there and build a new road instead.

Needless to say, this is a grossly inefficient way to treat arguably the single most important organ in the human body. The best approach would be to figure out how to resuscitate the deadened area, and in this quest, a group of researchers at Brown University and in India may have an answer.

The scientists turned to nanotechnology. In a lab, they built a scaffold-looking structure consisting of carbon nanofibers and a government-approved polymer. Tests showed the synthetic nanopatch regenerated natural heart tissue cells — called cardiomyocytes — as well as neurons. In short, the tests showed that a dead region of the heart can be brought back to life.

“This whole idea is to put something where dead tissue is to help regenerate it, so that you eventually have a healthy heart,” said David Stout, a graduate student in the School of Engineering at Brown and the lead author of the paper published in Acta Biomaterialia. …

What is unique about the experiments at Brown and at the India Institute of Technology Kanpur is the engineers employed carbon nanofibers, helical-shaped tubes with diameters between 60 and 200 nanometers. The carbon nanofibers work well because they are excellent conductors of electrons, performing the kind of electrical connections the heart relies upon for keeping a steady beat. The researchers stitched the nanofibers together using a poly lactic-co-glycolic acid polymer to form a mesh about 22 millimeters long and 15 microns thick and resembling “a black Band Aid,” Stout said. They laid the mesh on a glass substrate to test whether cardiomyocytes would colonize the surface and grow more cells.

In tests with the 200-nanometer-diameter carbon nanofibers seeded with cardiomyocytes, five times as many heart-tissue cells colonized the surface after four hours than with a control sample consisting of the polymer only. After five days, the density of the surface was six times greater than the control sample, the researchers reported. Neuron density had also doubled after four days, they added.

One reason this result is so interesting is that the approach used was conceptually so simple. A single simple and inexpensive nanomaterial, carbon nanofibers, was used to stimulate regeneration of natural heart tissue—there was no need for special molecular modification of the nanomaterial or added stem cells.
