Engineered bacteria provide new tool for nanotechnology protein design

Early in the evolution of thinking about protein engineering as a path toward advanced nanotechnology and molecular manufacturing, it was suggested that the road to designing proteins that would fold predictably would be made easier if it were possible to incorporate into proteins amino acids other than the twenty that naturally occur in biological systems. Early efforts were largely limited to chemically synthesized peptides. Efforts to trick biological systems into incorporating unnatural amino acid were limited to an occasional replacement. Now researchers at the Salk Institute for Biological Studies have succeeded in creating bacteria that efficiently incorporate unnatural amino acids into proteins at multiple sites. ScienceDaily points to this EurekAlert news release from the Salk Institute “Bionic bacteria may help fight disease and global warming“:

A strain of genetically enhanced bacteria developed by researchers at the Salk Institute for Biological Studies may pave the way for new synthetic drugs and new ways of manufacturing medicines and biofuels, according to a paper published September 18 in Nature Chemical Biology [abstract].

For the first time, the scientists were able to create bacteria capable of effectively incorporating “unnatural” amino acids – artificial additions to the 20 naturally occurring amino acids used as biological building blocks – into proteins at multiple sites. This ability may provide a powerful new tool for the study of biological processes and for engineering bacteria that produce new types of synthetic chemicals.

“This provides us with a lot more room to think about what we can do with protein synthesis,” said Lei Wang, assistant professor in Salk’s Chemical Biology and Proteomics Laboratory and holder of the Frederick B. Rentschler Developmental Chair. “It opens up new possibilities, from creating drugs that last longer in the blood stream to manufacturing chemicals in a more environmentally friendly manner.”

In 2001, Wang and his colleagues were the first to create bacteria that incorporated unnatural amino acids (Uaas) into proteins, and, in 2007, they first used the technique in mammalian cells. They did this by creating an “expanded genetic code,” overriding the genetic code of the cells and instructing them to use the artificial amino acids in the construction of proteins.

The addition of Uaas changes the chemical properties of proteins, promising new ways to use proteins in research, drug development and chemical manufacturing.

For instance, Wang and his colleagues have inserted Uaas that will glow under a microscope when exposed to certain colors of light. Because proteins serve as the basis for a wide range of cellular functions, the ability to visualize this machinery operating in live cells and in real time helps scientists decipher a wide range of biological mechanisms, including those involved in the development of disease and aging.

Genetically modified bacteria are already used for producing medicines, such as synthetic insulin, which has largely replaced the use of animal pancreases in the manufacture of drugs used by diabetics to regulate their blood sugar levels.

To date, such recombinant DNA technology has used only natural amino acids, which limits the possible functions of the resulting protein products. The ability to insert Uaas could dramatically expand the possible uses of such technology, but one major barrier has limited the use of Uaas: only a single Uaa at a time could be incorporated into a protein.

To insert the instructions for including a Uaa in a bacterium’s genetic code, Wang and his colleagues exploited stop codons, special sequences of code in a protein’s genetic blueprint. During protein production, stop codons tell the cellular machinery to stop adding amino acids to the sequence that forms backbone of the protein’s structure.

In 2001, Wang and his colleagues modified the genetic sequence of the bacteria Escherichia coli to selectively include a stop codon and introduced engineered molecules inside the bacteria, which surgically insert a Uaa at the stop codon. This trained the bacteria to produce proteins with the Uaa incorporated in their backbone.

The problem was that another biological actor, a protein known as release factor 1 (RF1), would stop the production of a Uaa-containing protein too early. Although scientists could insert stop codons for Uaas at multiple places along genetic sequence, the release factor would cut the protein off at the first stop codon, preventing production of long proteins containing multiple Uaas.

“To really make use of this technology, you want to be able to engineer proteins that contain unnatural amino acids at multiple sites, and to produce them in high efficiency,” Wang said. “It was really promising, but, until now, really impractical.”

In their new paper, the Salk researchers and their collaborators at the University of California, San Diego described how they got around this limitation. Since RF1 hindered production of long Uaa-containing proteins, the scientists removed the gene that produces RF1. Then, because E. Coli dies when the RF1 gene is deleted, they altered production of an alternative actor, release factor 2 (RF2), so that it could rescue the engineered bacterium.

The result was a strain of bacteria capable of efficiently producing proteins containing Uaas at multiple places. These synthetic molecules hold promise for the development of drugs with biological functions far beyond what is possible with proteins that include only naturally occurring amino acids. They may also serve as the basis for manufacturing everything from industrial solvents to biofuels, possibly helping to address the economic and environmental concerns associated with petroleum-based manufacturing and transportation.

“This is the first time we’ve been able to produce a viable strain of bacteria capable of this,” Wang said. “We still have a ways to go, but this makes the possibility of using unnatural amino acids in biological engineering far closer to being reality.”

The emphasis of both the news release and of the researchers is on the near term applications of this new ability in biotechnology, but we can also hope it will encourage investigations into designing proteins that fold more predictably.
